China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank

Quantity:

Multi Stage Industrial Food Grade Stainless Steel Movable Mixing Tank


Detailed Information
Feature
1. There are 600L-20000L variety of specifications, it can be designed, customized according to the customers' requirements.
2. Nsulation material is rock wool (keep warm) or PU (Keep cool)
3. Connector use tri-clamp, inner tank use SS304 OR SS316L, the inner surface mirror polishing.
4. Ra≤0.4μm, outer surface can be polishing, wiredrawing, sandblasting according to customers' requirement.


Application
• Water treatment: NF, UF, RO and ion exchange resin, etc.
• Food and beverage industry: filtration of juice, tea drinks, beer, liquor, wine, rice  wine, healthy drinks and bottled purified water, etc.
• Drugs industry: injections, medical filtration, biologic extraction, purification and concentration.
• Petrochemical industry: oil extraction reinjection, chemical reagents, lubricant and high-purity chemical was filtered.
• The electronic industry: electronic and microelectronics, semiconductor industry water filtration.
• Fine chemicals industry: bio-engineering, oil refined, cleaning mixture, scientific experiments, etc.

Design Parameter
Design pressure ATM~0.6Mpa
Design temperature According to the customers' requirements(0ºC~160ºC)

Surface Finish
Finish type Mechanical polishing, electrolytic polishing, sand blasting, picking
Polishing precision Mirror Polish Ra≤0.4μm

Connection
Inner-outlet Tri-clamo, Flange, Thread

Normal Model And Main Technical Parameters
Parameter Model CYGCD-75 CYGCD-150 CYGCD-300 CYGCD-600 CYGCD-1000 CYGCD-2000
Effective volume:L 75 150 300 600 1000 2000
Barrel Diameter:mm Ф250 Ф600 Ф800 Ф1000 Ф1100 Ф1300
Height:mm 460 550 600 800 1000 1500
Mixing Motor power:KW 0.37 0.55 0.75 0.75 1.1 1.5
Mixing work RPM :r/min 200(propeller) (The design can be adjusted according to customers' usage)

China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank
The above-mentioned data is the standard, it can customize according to customer's requirements.



Company Show
China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank
China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank
China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank
China 1000L Jacketed Heated Heating Stainless Steel Juice Wine Beer Food Mixing Agitator Tank
