Industrial RO Water System Filter Top Entry Bag Filter Housing

Quantity:

Industrial Water Filters Top Entry Bag Filters


Industrial RO Water System Filter Top Entry Bag Filter Housing


Surface Finish
Finish Type Mechanical polishing, Electrolytic
Polishing, Sand blasting, picking
Polishing
pressure
Mirror Polish Ra≤0.4μm

Operating Conditions
Max Operating
pressure.
1.0MPa
Max Operating
Temp.
150ºC

Material
Shell 304, 316L
O-ring EPDM, PTFE, Viton, Silicone

Connection
Shell Connection Flange
In-outlet Flange,Quick-open, Screw thread
Pressure Gauge
(optional)
M14×1.5 Female Screw thread
Vent Valve(optional) 1/4'' Male Screw thread

The above-mentioned data is the standard, it can customize according to customer's requirements.
