It is a improved small tube strainer which can remove a small amount of solid particles in the liquid, also can protect compressor, pump, instruments and other equipment to work normally.
Using multichannel polishing processing to ensure the interface Ra reach to 0.6μm close to sanitary level. All of the surface is mirror polished.
• Food & Pharmaceutical's production area: beverage, beer, drugs, dairy and etc.
• Corrosive in the chemical production process, such as: caustic soda, soda ash, carbonate, etc.
• Weak corrosively medium for petrochemical production, such as: water, ammonia, oil, hydrocarbon products and etc.
• Subzero treatment in the process of refrigeration: liquid ammonia, liquid oxygen and all kinds of refrigerant.
|Treatment Type||Mechanical polishing, electrolytic polishing, sand blasting, picking|
|Polishing precision||Mirror Polish Ra≤0.4μm|
|Max Operating pressure||0.6MPa, 1.0MPa|
|Max Operating Temp||140ºC|
|Shell connection||Flange (Eyebolt)|
|In-outlet N1, N2||Flange, thread, Tri-clamp|
|Vent valve N3(optional)||3/4'' male thread|
|Drain valve N4(optional)||1'' male thread|
|Dimension Parameters||1 basket|
|In-outlet 2''||In=outlet 3''|
|A: Total height |
(excluding filter cover)
|B: The distance from inlet to center||230|
|D: The height from in-outlet N1, N2 to ground||300||360|
|E: Drain port N4 height from the ground||60|
