Liquid mixing equipment Stainless Steel Water Mobile Storage Tank

Product description:

1. Name: stainless steel mobile tank, stainless steel storage tank;

2. Specifications: 100L, 200L, 500L, 1000L, 2000L, etc. (can be customized according to user requirements);

3. Material quality: SUS304, SUS316L, etc.;

4. Application: It is widely used in the preparation or storage of fluid materials in the fields of pharmacy, food, wine, beverage, food, daily chemical, chemical, biological engineering, etc.

5. Description: The storage tank adopts a fully enclosed structure and is made of high-quality stainless steel. It can be equipped with an automatic cleaning device and an automatic liquid level control device. The sterilization device can be installed according to user requirements to achieve aseptic storage. It is for storing mineral water. , The most ideal storage equipment for pure water and other liquids.

The internal surface of the stainless steel mobile tank is mirror polished, and the external surface can be polished, sandblasted or sandblasted according to customer requirements.
  • CHUANYA
  • 1
  • US $150/ Piece
  • Wooden
  • L/C, T/T
  • 1000PCS/ Month
  • Mirror Polish, Electro Polish Ra<0.4um
  • 1.0MPa
  • Ss 304/316/316L
  • Electric Power
  • Flange
  • 0~250c
  • Ningbo, China
Availability:
Quantity:

PDF Export

Application
Suitable for the pharmaceutical industry of pure water storage, injection water storage, liquid storage, intermediate buffer, also applies to normal temperature and warming storage of the food, milk, juice etc.

Feature

1. There are 600L-20000L variety of specifications, it can be designed, customized according to the customers' requirements.
2. Nsulation material is rock wool (keep warm) or PU (Keep cool)
3. Connector use tri-clamp, inner tank use SS304 OR SS316L, the inner surface mirror polishing.
4. Ra≤0.4μm, outer surface can be polishing, wiredrawing, sandblasting according to customers' requirement.
About US
The Payment Term:
TT 40% down payment and 70% balance agaisnt copy of B/L,L/C also can be accepted.
Delivery Date:
5-10 days according to different product.
The Transport Pattern:
Sea shipping or air transport.
Package way:
Wooden case
The Logo Issue:
If quantity is large,it absolutely no problem to do OEM.

Detailed Information

Design Parameter
Design pressure ATM~0.6Mpa
Design temperature According to the customers' requirements(0ºC~160ºC)

Surface Finish
Finish type Mechanical polishing, electrolytic polishing, sand blasting, picking
Polishing precision Mirror Polish Ra≤0.4μm

Connection
Inner-outlet Tri-clamo, Flange, Thread

Normal Model And Main Technical Parameters
Parameters Model CYGCD-600 CYGCD-1000 CYGCD-2000 CYGCD-3000 CYGCD-4000
Effective volume: L 600 1000 2000 3000 4000
Barrel Diameter:mm Ф600 Ф1100 Ф1300 Ф1600 Ф1700
Height/length: mm 900 1000 1500 1500 1800
Mixing Motor power:kw 1.1 1.5 2.2 2.2 3
Mixing work RPM:r/min 60(The design can be adjusted according to customers' request )
CYGCD-6000 CYGCD-8000 CYGCD-10000 CYGCD-12000 CYGCD-15000 CYGCD-20000
6000 8000 10000 12000 15000 20000
Ф1900 Ф2000 Ф2200 Ф2400 Ф2600 Ф2800
2000 2200 2400 2500 2700 3000
4 5.5 7.5 7.5 11 11

Liquid Stainless Steel Water Mobile Storage Tank

The above-mentioned data is the standard, it can customize according to customer's requirements.
