Stainless Steel Basket Filter Housing for Milk and Juice

Quantity:

PDF export

High Quality Stainless Steel Basket Filter Housing for Waste Water Stystem

Features
   Shell inner and outer surface all used mirror polished, ensure that the material liquid contact surface Ra reached 0.6μm close to the sanitary requirement.
  Filter shell can use Eyebolt connection or quick-open connection, which is convenient for operation and economical and practical.


Surface
Treatment Type Mechanical polishing, electrolytic polishing, sand blasting, picking
Polishing precision Mirror Polish Ra≤0.4μm

Operating Conditions
Max Operating pressure 0.6MPa, 1.0MPa
Max Operating Temp 140ºC

Connection
Shell connection Flange (Eyebolt)
In-outlet N1, N2 Flange, thread, Tri-clamp
Vent valve N3(optional) 3/4''  male thread
Drain valve N4(optional) 1'' male thread
Dimension Parameters 1 basket
In-outlet 2'' In=outlet 3''
A: Total height
(excluding filter cover)
500 580
B: The distance from inlet to center 230
C: Diameter Ф6''
D: The height from in-outlet N1, N2 to ground 300 360
E: Drain port N4 height from the ground 60

The above-mentioned data is the standard, it can customize according to customer's requirements.
