Storage mobile water Tank mixing equipment

Product description:

1. Name: stainless steel mobile tank, stainless steel storage tank;

2. Specifications: 100L, 200L, 500L, 1000L, 2000L, etc. (can be customized according to user requirements);

3. Material quality: SUS304, SUS316L, etc.;

4. Application: It is widely used in the preparation or storage of fluid materials in the fields of pharmacy, food, wine, beverage, food, daily chemical, chemical, biological engineering, etc.

5. Description: The storage tank adopts a fully enclosed structure and is made of high-quality stainless steel. It can be equipped with an automatic cleaning device and an automatic liquid level control device. The sterilization device can be installed according to user requirements to achieve aseptic storage. It is for storing mineral water. , The most ideal storage equipment for pure water and other liquids.

The internal surface of the stainless steel mobile tank is mirror polished, and the external surface can be polished, sandblasted or sandblasted according to customer requirements.
  • MT
  • CHUANYA
  • 7310299000
  • 1
  • US $100-1000
  • Wooden
  • Stainless Steel
  • Water
  • L/C, T/T
  • 1000PCS/ Month
  • Mirror Polish, Electro Polish Ra<0.4um
  • Water Purifier
  • Food,Beverage, Water
  • 1.0MPa
  • CE, SGS, ISO 9001
  • Ss 304/316/316L
  • Electric Power / Pressure
  • Flange
  • 0~250c
  • Ningbo, China
Availability:
Quantity:

PDF Export

Feature

• Realize flexible mobile, with buffer storage function, and can add mixing, cleaning, heating or cooling function.
• reasonable design of the brake wheel, pedal or forklift groove, suitable for raw materials or finished product of mobile, convenient off-line cleaning.
• Can be optional of single layer tank or jacket form or there layer with insulation;
• There are 75L~2000L variety of specifications, it can be designed, customized according to the customers' requirements.


Application
• Water treatment: NF, UF, RO and ion exchange resin, etc.
• Food and beverage industry: filtration of juice, tea drinks, beer, liquor, wine, rice  wine, healthy drinks and bottled purified water, etc.
• Drugs industry: injections, medical filtration, biologic extraction, purification and concentration.
• Petrochemical industry: oil extraction reinjection, chemical reagents, lubricant and high-purity chemical was filtered.
• The electronic industry: electronic and microelectronics, semiconductor industry water filtration.
• Fine chemicals industry: bio-engineering, oil refined, cleaning mixture, scientific experiments, etc.


Detailed Information

Design Parameter
Design pressure ATM~0.6Mpa
Design temperature According to the customers' requirements(0ºC~160ºC)

Surface Finish
Finish type Mechanical polishing, electrolytic polishing, sand blasting, picking
Polishing precision Mirror Polish Ra≤0.4μm

Connection
Inner-outlet Tri-clamo, Flange, Thread

Normal Model And Main Technical Parameters
Parameter Model CYGCD-75 CYGCD-150 CYGCD-300 CYGCD-600 CYGCD-1000 CYGCD-2000
Effective volume:L 75 150 300 600 1000 2000
Barrel Diameter:mm Ф250 Ф600 Ф800 Ф1000 Ф1100 Ф1300
Height:mm 460 550 600 800 1000 1500
Mixing Motor power:KW 0.37 0.55 0.75 0.75 1.1 1.5
Mixing work RPM :r/min 200(propeller) (The design can be adjusted according to customers' usage)

The above-mentioned data is the standard, it can customize according to customer's requirements.
