China Manufacturer Beer Lenticular Disks Filter Cartridges
Description:
Depth-Stack Filter Cartridges are a new type of filter cartridge using depth filter sheets. It is designed using a double separator concept. The Separator design increases the total stability of the filter cartridges as the separators fully support the sheet material. This design also prevents filter sheet deformities after heat treatment and adverse effects from hot sanitation. It is manufactured with rigid external clips to prevent damaging filter sheets during module loading and unloading while allowing for easy and reliable handling.
| Dimension | OD | 8 " , 12 " , 16 " , |
Material of Constructions | Depth filter sheet | Cellulose fibers, Resins,Perlite, Natural diatomaceous earths, and etc |
| Core | Polypropylene (PP) | |
| Separator | Polypropylene (PP) | |
| Double O-ring | Silicone, EPDM, Viton | |
| Flat gasket | Silicone, EPDM, Viton | |
| Construction | 7 Cell , 8 Cell , 9 Cell , 12 Cell , 14 Cell , 15 Cell , 16 Cell | |
| Performance | Typical ratings | C002:0.2-0.4µm |
| C004:0.4-0.6μm | ||
| C100:1-3µm | ||
| C150:2-5µm | ||
| C200:3-7µm |
